Feature：
1.lmported PLC with colorful touch screen multilingual easy to operate；
2.lmported servo and sensor for film precise positioning working steadily；
3. Double belt for film feeding structure for stably and precise operation；
4.Multifunctional alarm to reduce wastage and safe operation；
5. Intelligent temperature control system automatically rectification function6.Different date printing mode optional.
Specification
Model | XLY-420 |
Bag Length | 80-350mm |
Bag Width | 150-200mm |
Packing Speed | 45-60 Bags/min |
Film Width | 420mm (Max) |
Film roll diameter | 0.04-0.09(mm) |
Air Pressure | 0.8Mpa 0.5m³/min |
Power | 2.2kw 220v 50Hz |
Filling Range | Max4000ml |
Dimension | (L)1500*(W)1120*(H)1610mm |
Net Weight | 550kg |
