n Advanced HMI operation, PLC control;

n 316L stainless steel is adopted for parts contacting materials; the appearance is 304 stainless steel, conforming to food sanitation standards.

n Precision stainless steel piston cylinder processing technology guarantees accurate and consistent filling, and makes seal ring more durable;

n Variable frequency driving, human-machine interface sets filling volume, and it is easy to wash;

n This equipment is applicable to the filling of various sauce, cream, liquid, which has strong versatility.

Scope of application:

n Filling of various kinds of liquid, cream, sauce (containing soft particles) (honey, chilli sauce, pearl milk tea, coconuts, orange juice, etc.), which has strong versatility.

Item

XL-120-12

XL-500-12

XL-1000-12

XL-2500-12

XL-5000-12

Filling scope

(10-120)ml×12

(50-500)ml×12

(100-1000)ml×12

(250-2500)ml×12

(500-5000)ml×12

Filling speed

bottles/min (Single-channel)

bottles/min(Double-channel)

Filling precision

≦±1液体liquid   ≦±2膏体liquid cream

Power

AC380V/50/60Hz 3.5KW

Weight

1370㎏

Barometric range

0.4-0.6Mpa

Host dimension

5210×1315×2170mm
