Feature：
1.lmported PLC with colorful touch screen multilingual easy to operate；
2.lmported servo and sensor for film precise positioning working steadily；
3. Double belt for film feeding structure for stably and precise operation；
4.Multifunctional alarm to reduce wastage and safe operation；
5. Intelligent temperature control system automatically rectification function6.Different date printing mode optional.
Technical Parameters
Type | XLY-1020 | XLY-820 | XLY-720 | XLY-620 | XLY-520 | XLY-420 |
Bag length | 100-800mm(L) | 100-700mm(L) | 100-450mm(L) | 100-400mm(L) | 100*350mm(L) | 50*300mm(L) |
Bag width | 100-500mm(W) | 100-400mm(W) | 100-350mm(W) | 100-300mm(W) | 100-250mm(W) | 80-200 |
Max roll film width | 1020mm | 820mm | 720mm | 620MM | 520MM | 420MM |
Packing speed | 5-60 bag/min | 5-60 bag/min | 5-60 bag/min | 5-60 bag/min | 5-80 bag/min | 5-80 bag/min |
Air consumption | 0.65 m3/min 1.0Mps | 0.65 m3/min 1.0Mps | 0.65 m3/min 1.0Mps | 0.65 m3/min 1.0Mps | 0.65 m3/min 1.0Mps | 0.65 m3/min 1.0Mps |
Power voltage | 6KW 220V 50/60HZ | 6KW 220V 50/60HZ | 3KW 220V 50/60HZ | 2.7KW 220V 50/60HZ | 2.5KW 220V 50/60HZ | 2KW 220V 50/60HZ |
