Sealing   Type

High   Speed Continuous Sealing

Installed   Power

380V/50-60HZ/3Phase

Packing   Capacity

Max. 70   Packs per Minute (Depends on Product Size)

Sealing   Height

170MM

Packing   Width

350MM

Conveyor   Speed

Variable,   30M/Min

Film   Thickness

12-30   Micron (Minimum-Maximum)

Packing   Size

Width +   Height < 450MM

Film   Type

Center   Folded POF/ PE Film

Max Film   Roll Size

530MM   (Width) X 280MM (Outer Diameter)

Power   Consumption

3 KW

Working   Height

780-850   MM

Air   Pressure

0.5MPA   (5 BAR)

Sealing   Knife

Special   Durable Alloyed Sealing Knife with Anti-Stick Teflon Coats

Operating   Panel

Siemens   Colorful Touch Screen, PLC.

Machine   Material

Carbon Steel

Sealing   Machine Dimensions

1825 X   1515 X 1350 MM
