Pouch Type

Pillow bag, 3 & 4 side seal bag

Stand-up bag, Gusseted bag, Handle bag, Spout bag, Paper bag, Zipper bag (for option)

Working Station

Six working station

Eight working station

Pouch

W

100-200mm

100-300mm

200-300mm

100-450mm

100-200mm

100-300mm

200-300mm

100-450mm

L

Capacity

Up to 50 bags/ min (product property and filling range count)

Filling Range

0-3000g

Dosing Systems

Multi-head combination scale, Linear scale, Volumetric cup, Auger filler, Piston filler, etc.

Voltage

AC380V/50Hz, three phases (or customize according to specific demands)

Power

3.5KW

3.5KW

3.5KW

3.5KW

Air Sourse

0.4 CBM/ min (offered by the user)

Machine’s Dimension

1650x1380x1500mm

2200x1850x1500mm

2200x1850x1500mm

2200x1850x1500mm

Machine’s Weight

1060 Kg

1280Kg

1250Kg

1060Kg
